Staying Hidden on the Endpoint: Evading Detection with Shellcode

True red team assessments require a secondary objective of avoiding detection. Part of the glory of a successful red team assessment is not getting detected by anything or anyone on the system. As modern Endpoint Detection and Response (EDR) products have matured over the years, the red teams must follow suit. This blog post will provide some insights into how the FireEye Mandiant Red Team crafts payloads to bypass modern EDR products and get full command and control (C2) on their victims’ systems.

Shellcode injection or its execution is our favorite method for launching our C2 payload on a victim system; but what is shellcode? Michael Sikorski defines shellcode as a “…term commonly used to describe any piece of self-contained executable code” (Practical Malware Analysis). Most commercial Penetration Testing Frameworks such as Empire, Cobalt Strike, or Metasploit have a shellcode generator built into the tool. The shellcode generator is generally in either a binary format or hex format depending on whether you generate it as raw output or as an application source.

Why do we use shellcode for all our payloads?

The use of shellcode in our red team assessment payloads allows us to be incredibly flexible in the type of payload we use. Shellcode runners can be in written in a wide range of programming languages that can be incorporated into many types of payloads. This flexibility allows us to customize our payloads to support the specific needs of our clients and of any given situation that may arise during a red team assessment. Since shellcode can be launched from inside a payload or injected into an already running process, we can use several techniques to increase the ability of our payloads to evade detection from EDR products depending on the scenario and technology in place in the target environment. Several techniques exist for obfuscating shellcode, such as encryption and custom encoding, that make it difficult for EDR products to detect shellcode from commercial C2 tools on its own. The flexibility and evasive properties of shellcode are the primary reason that we rely heavily on shellcode based payloads during red team assessments.

Shellcode Injection Vs. Execution

One of the most crucial parts of any red team assessment is developing a payload that will successfully, reliably, and stealthily run on the target system. Payloads can either execute shellcode from within its own process or inject shellcode into the address space of another process that will ultimately execute the shellcode. For the purposes of this blog post we’ll refer to shellcode injection as shellcode executed inside a remote process and shellcode execution as shellcode executed inside the payload process.

Shellcode injection is one technique that red teams and malicious attackers use to avoid detection from EDR products and network defenders. Additionally, many EDR products implement detections based on expected behavior of windows processes. For example, an attacker that executes Mimikatz from the context of an arbitrary process, let’s say DefinitelyNotEvil.exe, may get detected or blocked outright because the EDR tool does not expect that process to access lsass.exe. However, by injecting into a windows process, such as svchost.exe, that regularly touches lsass.exe, it may be possible to bypass these detections because the EDR product sees this as an expected behavior.

In this blog post, we’ll cover three different techniques for running shellcode.

  • CreateThread
  • CreateRemoteThread
  • QueueUserAPC

Each of these techniques corresponds to a Windows API function that is responsible for the allocation of a thread to the shellcode, ultimately resulting in the shellcode being run. CreateThread is a technique used for shellcode execution while CreateRemoteThread and QueueUserAPC are forms of shellcode injection.

The following is a high-level outline of the process for running shellcode with each of the three different techniques.

CreateThread
  1. Allocate memory in the current process
  2. Copy shellcode into the allocated memory
  3. Modify the protections of the newly allocated memory to allow execution of code from within that memory space
  4. Create a thread with the base address of the allocated memory segment
  5. Wait on the thread handle to return
CreateRemoteThread
  1. Get the process ID of the process to inject into
  2. Open the target process
  3. Allocate executable memory within the target process
  4. Write shellcode into the allocated memory
  5. Create a thread in the remote process with the start address of the allocated memory segment


Figure 1: Windows API calls for CreateRemoteThread injection

QueueUserAPC
  1. Get the process ID of the process to inject into
  2. Open the target process
  3. Allocate memory within the target process
  4. Write shellcode into the allocated memory
  5. Modify the protections of the newly allocated memory to allow execution of code from within that memory space
  6. Open a thread in the remote process with the start address of the allocated memory segment
  7. Submit thread to queue for execution when it enters an “alertable” state
  8. Resume thread to enter “alertable” state


Figure 2: Windows API calls for QueueUserAPC injection

Command Execution

Let’s break down what we’ve talked about so far:

  • Malicious code is your shellcode – the stage 0 or stage 1 code that is truly going to do the malicious work.
  • Standard “shellcode runner” application which executes your code via either injection or execution. Most everyone writes their own shellcode runner, so we don’t necessarily deem this as true malware, the real malware is the shellcode itself.

Now that we’ve covered all that, we need a method to execute the code you compiled. Generally, this is either an executable (EXE) or a Dynamic Link Library (DLL). The Red Team prefers using Living Off the Land Binaries (lolbins) commands which will execute our compiled code.

The reason we can take advantage of lolbins is because of unmanaged exports. At a high level, when an executable calls a DLL it is looking for a specific export within the DLL to execute the code within that export. If the export is not properly protected, then you can craft your own DLL with the export name you know the executable is looking for and run your arbitrary code; which in this case will be your shellcode runner.

Putting It All Together

We set out to develop a shellcode runner DLL that takes advantage of lolbins through unmanaged exports while also providing the flexibility to execute both injected and non-injected shellcode without a need to update the code base. This effort resulted in a C# shellcode runner called DueDLLigence, for which the source code can be found at the GitHub page.

The DueDLLigence project provides a quick and easy way to switch between different shellcode techniques described previously in this blog post by simply switching out the value of the global variable shown in Figure 3.


Figure 3: Shellcode technique variable

The DueDLLigence DLL contains three unmanaged exports inside of it. These exports can be used with the Rasautou, Control, and Coregen native Windows commands as described in Figure 4. Note: The shellcode that is in the example will only pop calc.

Native Windows Executable

Required Export Name

Syntax Used To Run

Rasautou

Powershell

rasautou –d {full path to dll} –p powershell –a a –e e

Control

Cplapplet

Rename compiled “dll” extension to “cpl” and just double click it!

MSIExec

Dllunregisterserver

msiexec /z {full path to dll}

Figure 4: DueDLLigence execution outline

When you open the source code you will find the example uses the exports shown in Figure 5.


Figure 5: Source code for exported entry points

The first thing you should do is generate your own shellcode. An example of this is shown in Figure 6, where we use Cobalt Strike to generate raw shellcode for the “rev_dns” listener. Once that is complete, we run the base64 -w0 payload.bin > [outputFileName] command in Linux to generate the base64 encoded version of the shellcode as shown in Figure 7.


Figure 6: Shellcode generation


Figure 7: Converting shellcode to base64

Then you simply replace the base64 encoded shellcode on line 58 with the base64'd version of your own x86 or x64 shellcode. The screenshot in Figure 6 generated an x86 payload, you will need to check the “use x64 payload” box to generate an x64 payload.

At this point you should reinstall the Unmanaged exports library in the DueDLLigence Visual Studio project because sometimes when you’re using a different project it doesn’t work properly. You can reinstall opening the NuGet package manager console shown in Figure 8 and running the Install-Package UnmanagedExports -Version 1.2.7 command.


Figure 8: Open NuGet Package Manager

After you have reinstalled the Unmanaged exports library and replaced the base64 encoded shellcode on line 58 then you are ready to compile! Go ahead and build the source and look for your DLL in the bin folder. We strongly suggest that you test your DLL to ensure it has the proper exports associate with it. Visual Studio Pro comes with the Dumpbin.exe utility which you can run against your DLL to view the exports as shown in Figure 9.


Figure 9: Dumpbin.exe output

You can expand the list as much as you want with more lolbin techniques found over at the GitHub page.

We prefer to remove the unmanaged exports that are not going to be used with the respective payload that was generated so there is a smaller footprint in the payload. In general, this is good tradecraft when crafting payloads or writing code. In our industry we have the principle of least privilege, well this is the principle of least code!

Modern Detections for Shellcode Injection

Despite all the evasive advantages that shellcode offers, there is hope when it comes to detecting shellcode injection. We looked at several different methods for process injection.

In our shellcode runner, the shellcode injection techniques (CreateRemoteThread and QueueUserAPC) spawn a process in a suspended state and then inject shellcode into the running process. Let’s say we choose the process to inject into as explorer.exe and our payload will run with MSIExec. This will create a process tree where cmd.exe will spawn msiexec.exe which will in turn spawn explorer.exe.


Figure 10: Process tree analysis

In an enterprise environment it is possible to collect telemetry data with a SIEM to determine how often, across all endpoints, the cmd.exe -> msiexec.exe -> explorer.exe process tree occurs. Using parent-child process relationships, defenders can identify potential malware through anomaly detection.

API hooking is commonly used by EDR and AV products to monitor and for detect the use of Windows API calls that are commonly used by malware authors. Utilizing kernel routines such as PsSetCreateProcessNotifyRoutine(Ex) and PsSetCreateThreadNotifyRoutine(Ex), security software can monitor when certain API calls are used, such as CreateRemoteThread. Combining this information with other data such as process reputation and enterprise-wide telemetry can be used to provide high fidelity alerts for potential malware.

When process injection occurs, one process modifies the memory protections of a memory region in another process’s address space. By detecting the use of API calls such as VirtualProtectEx that result in one process modifying the memory protections of address space allowed to another process, especially when the PAGE_EXECUTE_READWRITE permissions are used as this permission is used to allow the shellcode to be written and executed within the same memory space.

As red teamers and malicious actors continue to develop new process injection techniques, network defenders and security software continue to adapt to the ever-changing landscape. Monitoring Windows API function calls such as VirtualAllocEx, VirtualProtectEx, CreateRemoteThread, and NTQueueAPCThread can provide valuable data for identifying potential malware. Monitoring for the use of CreateProcess with the CREATE_SUSPENDED and CREATE_HIDDEN flags may assist in detecting process injection where the attacker creates a suspended and hidden process to inject into.

As we’ve seen, process injection techniques tend to follow a consistent order in which they call Windows API functions. For example, both injection techniques call VirtualAllocEx followed by WriteProcessMemory and identifying when a process calls these two APIs in that order can be used as a basis for detecting process injection.

Conclusion

Using shellcode as the final stage for payloads during assessments allows Red Teams the flexibility to execute payloads in a wide array of environments while implementing techniques to avoid detection. The DueDLLigence shellcode runner is a dynamic tool that takes advantage of the evasive properties of both shellcode and process injection to offer Red Teams a way to avoid detection. Detections for the execution of LOLbins on the command line and process injection at the API and process level should be incorporated into defensive methodology, as attackers are increasingly being forced into living off the land with the increased adoption of application whitelisting.

Mahalo FIN7: Responding to the Criminal Operators’ New Tools and Techniques

During several recent incident response engagements, FireEye Mandiant investigators uncovered new tools in FIN7’s malware arsenal and kept pace as the global criminal operators attempted new evasion techniques. In this blog, we reveal two of FIN7’s new tools that we have called BOOSTWRITE and RDFSNIFFER.

The first of FIN7's new tools is BOOSTWRITE – an in-memory-only dropper that decrypts embedded payloads using an encryption key retrieved from a remote server at runtime. FIN7 has been observed making small changes to this malware family using multiple methods to avoid traditional antivirus detection, including a BOOSTWRITE sample where the dropper was signed by a valid Certificate Authority. One of the analyzed BOOSTWRITE variants contained two payloads: CARBANAK and RDFSNIFFER. While CARBANAK has been thoroughly analyzed and has been used maliciously by several financial attackers including FIN7, RDFSNIFFER is a newly-identified tool recovered by Mandiant investigators.

RDFSNIFFER, a payload of BOOSTWRITE, appears to have been developed to tamper with NCR Corporation's “Aloha Command Center” client. NCR Aloha Command Center is a remote administration toolset designed to manage and troubleshoot systems within payment card processing sectors running the Command Center Agent. The malware loads into the same process as the Command Center process by abusing the DLL load order of the legitimate Aloha utility. Mandiant provided this information to NCR.

BOOSTWRITE Loader: Where You At?

BOOSTWRITE is a loader crafted to be launched via abuse of the DLL search order of applications which load the legitimate ‘Dwrite.dll’ provided by the Microsoft DirectX Typography Services. The application loads the ‘gdi’ library, which loads the ‘gdiplus’ library, which ultimately loads ‘Dwrite’. Mandiant identified instances where BOOSTWRITE was placed on the file system alongside the RDFClient binary to force the application to import DWriteCreateFactory from it rather than the legitimate DWrite.dll.

Once loaded, `DWrite.dll` connects to a hard-coded IP and port from which it retrieves a decryption key and initialization vector (IV) to decrypt two embedded payload DLLs. To accomplish this task, the malware first generates a random file name to be used as a text log under the current user's %TEMP% directory; this filename starts with ~rdf and is followed by a set of random numbers. Next, the malware scans its own image to find the location of a 32-byte long multi-XOR key which is used to decode data inside its body. Part of the decoded data is an IP address and port which are used to retrieve the key and the IV for the decryption of the embedded payloads. The encryption algorithm uses the ChaCha stream cipher with a 256-bit key and 64-bit IV.

Once the key and the IV are downloaded the malware decrypts the embedded payloads and performs sanity checks on the results. The payloads are expected to be PE32.DLLs which, if the tests pass, are loaded into memory without touching the filesystem.

The malware logs various plaintext messages to the previously created logfile %TEMP%\~rds<rnd_numbers> which are indicative of the loader’s execution progress. An example of the file content is shown in Figure 1:

Loading...
Starting...
Init OK
Key OK
Data: 4606941
HS: 20
K:[32] V:[8]
DCnt: 732642317(ERR)

Figure 1: BOOSTWRITE log file

Before exiting, the malware resolves the location of the benign DWrite.dll library and passes the execution control to its DWriteCreateFactory method.

The malware decrypts and loads two payload DLLs. One of the DLLs is an instance of the CARBANAK backdoor; the other DLL is a tool tracked by FireEye as RDFSNIFFER which allows an attacker to hijack instances of the NCR Aloha Command Center Client application and interact with victim systems via existing legitimate 2FA sessions.

RDFSNIFFER Module: We Smell a RAT

RDFSNIFFER is a module loaded by BOOSTWRITE which allows an attacker to monitor and tamper with legitimate connections made via NCR Corporation’s ‘Aloha Command Center Client’ (RDFClient), an application designed to provide visibility and system management capabilities to remote IT techs. RDFSNIFFER loads into the same process as the legitimate RDFClient by abusing the utility’s DLL load order, launching each time the ‘Aloha Command Center Client’ is executed on an impacted system.

When the RDFSNIFFER module is loaded by BOOSTWRITE it hooks several Win32 API functions intended to enable it to tamper with NCR Aloha Command Center Client sessions or hijack elements of its user-interface (Table 1). Furthermore, this enables the malware to alter the user’s last input time to ensure application sessions do not time out.

Win32 API Function

Hook Description

CertVerifyCertificateChainPolicy

Used to man-in-the-middle SSL sessions

CertGetCertificateChain

Used to man-in-the-middle SSL sessions

WSAConnect

Used to man-in-the-middle socket connections

connect

Used to man-in-the-middle socket connections

ConnectEx

Used to man-in-the-middle socket connections

DispatchMessageW

Used to hijack the utility's UI

DispatchMessageA

Used to hijack the utility's UI

DefWindowProcW

Used to hijack the utility's UI

DefWindowProcA

Used to hijack the utility's UI

GetLastInputInfo

Used to change the user's last input time (to avoid timed lock outs)

Table 1: RDFSNIFFER’s Hooked Win32 API Functions

This module also contains a backdoor component that enables it to inject commands into an active RDFClient session. This backdoor allows an attacker to upload, download, execute and/or delete arbitrary files (Table 2).

Command Name

Legit Function in RDFClient

RDFClient Command ID

Description

Upload

FileMgrSendFile

107

Uploads a file to the remote system

Download

FileMgrGetFile

108

Retrieves a file from the remote system

Execute

RunCommand

3001

Executes a command on the remote system

DeleteRemote

FileMgrDeleteFile

3019

Deletes file on remote system

DeleteLocal

-

-

Deletes a local file

Table 2: RDFSNIFFER’s Backdoor Functions

Signed: Yours Truly, FIN7

While the majority of BOOSTWRITE variants recovered from investigations have been unsigned, Mandiant identified a signed BOOSTWRITE sample used by FIN7 during a recent investigation. Following that discovery, a signed BOOSTWRITE sample was uploaded to VirusTotal on October 3. This executable uses a code signing certificate issued by MANGO ENTERPRISE LIMITED (Table 3).

MD5

Organization

Country

Serial

a67d6e87283c34459b4660f19747a306

mango ENTERPRISE LIMITED

GB

32 7F 8F 10 74 78 42 4A BE B8 2A 85 DC 36 57 03 CC 82 70 5B

Table 3: Code signing certificate used for BOOSTWRITE

This indicates the operators may be actively altering this malware to avoid traditional detection mechanisms. Notably, the signed BOOSTWRITE sample had a 0/68 detection ratio when it was uploaded to VirusTotal, demonstrating the effectiveness of this tactic (Figure 2).


Figure 2: Current VirusTotal detection ratio for signed BOOSTWRITE

Use of a code signing certificate for BOOSTWRITE is not a completely new technique for FIN7 as the group has used digital certificates in the past to sign their phishing documents, backdoors, and later stage tools. By exploiting the trust inherently provided by code certificates, FIN7 increases their chances of bypassing various security controls and successfully compromising victims. The full evasion achieved against the detection engines deployed to VirusTotal – as compared to an unsigned BOOSTWRITE sample with an invalid checksum– illustrates that FIN7’s methods were effective in subverting both traditional detection and ML binary classification engines. This is a known issue and has been deeply studied since at least 2016’s “Chains of Distrust” research and 2017’s “Certified Malware” paper. Since there are plenty of goodware samples with bad or no signatures – and a growing number of malware samples with good signatures – there is no easy solution here. The upside is that vendors selectively deploy engines to VirusTotal (including FireEye) and VT detection performance often isn’t a comprehensive representation of encountering full security technology stacks that implement detection-in-depth. Later in this blog we further explore BOOSTWRITE’s PE Authenticode signature, its anomalies, and how code signing can be turned from a detection challenge into detection opportunities.

Outlook and Implications

While these incidents have also included FIN7’s typical and long-used toolsets, such as CARBANAK and BABYMETAL, the introduction of new tools and techniques provides further evidence FIN7 is continuing to evolve in response to security enhancements. Further, the use of code signing in at least one case highlights the group's judicious use of resources, potentially limiting their use of these certificates to cases where they have been attempting to bypass particular security controls. Barring any further law enforcement actions, we expect at least a portion of the actors who comprise the FIN7 criminal organization to continue conducting campaigns. As a result, organizations need to remain vigilant and continue to monitor for changes in methods employed by the FIN7 actors.

Sigs Up Dudes! Indicators, Toolmarks, and Detection Opportunities

While FireEye does not release our production detection logic for the code families, this section does contain some identification and hunting concepts that we adopt in our layered detection strategy. Table 4 contains malware samples referenced in this blog that FireEye is able to share from the larger set recovered during active investigations.

Type

Indicator(s)

BOOSTWRITE (signed)

MD5: a67d6e87283c34459b4660f19747a306
SHA-1: a873f3417d54220e978d0ca9ceb63cf13ec71f84
SHA-256: 18cc54e2fbdad5a317b6aeb2e7db3973cc5ffb01bbf810869d79e9cb3bf02bd5

C2: 109.230.199[.]227

BOOSTWRITE (unsigned)

MD5: af2f4142463f42548b8650a3adf5ceb2
SHA1: 09f3c9ae382fbd29fb47ecdfeb3bb149d7e961a1
SHA256: 8773aeb53d9034dc8de339651e61d8d6ae0a895c4c89b670d501db8dc60cd2d0

C2: 109.230.199[.]227

Table 4: Publicly-shareable BOOSTWRITE samples

The signed BOOSTWRITE sample has a PE Authenticode anomaly that can be detected using yara’s PE signature module. Specifically, the PE linker timestamp is prior to the Authenticode validity period, as seen in Table 5.

Timestamp

Description

2019-05-20 09:50:55 UTC

Signed BOOSTWRITE’s PE compilation time

2019-05-22 00:00 UTC
through
2020-05-21 23:59 UTC

Signed BOOSTWRITE’s “mango ENTERPRISE LIMITED” certificate validity window

Table 5: Relevant executabe timestamps

A public example of a Yara rule covering this particular PE Authenticode timestamp anomaly is available in a blog post from David Cannings, with the key logic shown in Figure 3.

pe.number_of_signatures > 0 and not for all i in (0..pe.number_of_signatures - 1):
     pe.signatures[i].valid_on(pe.timestamp)

Figure 3: Excerpt of NCC Group’s research Yara rule

There are other PE Authenticode anomalies that can also be represented as Yara rules to surface similarly suspicious files. Of note, this signed BOOSTWRITE sample has no counter signature and, while the unauthenticated attributes timestamp structure is present, it is empty. In preparing this blog, FireEye’s Advanced Practices team identified a possible issue with VirusTotal’s parsing of signed executable timestamps as seen in Figure 4.



Figure 4: Inconsistency in VirusTotal file signature timestamps for the signed BOOSTWRITE sample

FireEye filed a bug report with Google to address the discrepancy in VirusTotal in order to remove confusion for other users.

To account for the detection weaknesses introduced by techniques like code signing, our Advanced Practices team combines the malicious confidence spectrum that comes from ML detection systems with file oddities and anomalies (weak signals) to surface highly interesting and evasive malware. This technique was recently described in our own Dr. Steven Miller’s Definitive Dossier of Devilish Debug Details. In fact, the exact same program database (PDB) path-based approach from his blog can be applied to the toolmarks seen in this sample for a quick hunting rule. Figure 5 provides the PDB path of the BOOSTWRITE samples from this blog.

F:\projects\DWriteImpl\Release\DWriteImpl.pdb

Figure 5: BOOSTWRITE PDB path

The Yara rule template can be applied to result in the quick rule in Figure 6.

rule ConventionEngine_BOOSTWRITE
{
 meta:
     author = "Nick Carr (@itsreallynick)"
     reference = "https://www.fireeye.com/blog/threat-research/2019/08/definitive-dossier-of-devilish-debug-details-part-one-pdb-paths-malware.html"
strings:
     $weetPDB = /RSDS[\x00-\xFF]{20}[a-zA-Z]?:?\\[\\\s|*\s]?.{0,250}\\DWriteImpl[\\\s|*\s]?.{0,250}\.pdb\x00/ nocase
 condition:
     (uint16(0) == 0x5A4D) and uint32(uint32(0x3C)) == 0x00004550 and $weetPDB and filesize < 6MB
}

Figure 6: Applying BOOSTWRITE’s PDB path to a Yara rule

We can apply this same concept across other executable traits, such as BOOSTWRITE’s export DLL name (DWriteImpl.dll), to create quick and easy rules that can aid in quick discovery as seen in Figure 7.

rule Exports_BOOSTWRITE
{
meta:
     author = "Steve Miller (@stvemillertime) & Nick Carr (@itsreallynick)"
strings:
     $exyPants = "DWriteImpl.dll" nocase
condition:
     uint16(0) == 0x5A4D and uint32(uint32(0x3C)) == 0x00004550 and $exyPants at pe.rva_to_offset(uint32(pe.rva_to_offset(pe.data_directories[pe.IMAGE_DIRECTORY_ENTRY_EXPORT].virtual_address) + 12)) and filesize < 6MB
}

Figure 7: Applying BOOSTWRITE’s export DLL names to a Yara rule (Note: this rule was updated following publication. It previously read "module_ls.dll", which is for Turla and unrelated.)

Of course, resilient prevention capabilities are needed and to that end, FireEye detects this activity across our platforms. Table 6 contains several specific detection names from a larger list of detection capabilities that captured this activity natively.

Platform

Signature Name

Endpoint Security

MalwareGuard ML detection (unsigned variants)

Network Security and Email Security

Malware.binary.dll (dynamic detection)
MalwareGuard ML detection (unsigned variants)
APTFIN.Dropper.Win.BOOSTWRITE (network traffic)
APTFIN.Backdoor.Win.RDFSNIFFER (network traffic)
FE_APTFIN_Dropper_Win_BOOSTWRITE (static code family detection)
FE_APTFIN_Backdoor_Win_RDFSNIFFER (static code family detection)

Table 6: FireEye detection matrix

Don’t Sweat the Techniques – MITRE ATT&CK Mappings

BOOSTWRITE

ID

Tactic

BOOSTWRITE Context

T1022

Data Encrypted

BOOSTWRITE encodes its payloads using a ChaCha stream cipher with a 256-bit key and 64-bit IV to evade detection

T1027

Obfuscated Files or Information

BOOSTWRITE encodes its payloads using a ChaCha stream cipher with a 256-bit key and 64-bit IV to evade detection

T1038

DLL Search Order Hijacking

BOOSTWRITE exploits the applications’ loading of the ‘gdi’ library, which loads the ‘gdiplus’ library, which ultimately loads the local ‘Dwrite’ dll

T1116

Code Signing

BOOSTWRITE variants were observed signed by a valid CA

T1129

Execution through Module Load

BOOSTWRITE exploits the applications’ loading of the ‘gdi’ library, which loads the ‘gdiplus’ library, which ultimately loads the local ‘Dwrite’ dll

T1140

Deobfuscate/Decode Files or Information

BOOSTWRITE decodes its payloads at runtime using using a ChaCha stream cipher with a 256-bit key and 64-bit IV

RDFSNIFFER

ID

Tactic

RDFSNIFFER Context

T1106

Execution through API

RDFSNIFFER hooks several Win32 API functions intended to enable it to tamper with NCR Aloha Command Center Client sessions or hijack elements of its user-interface

T1107

File Deletion

RDFSNIFFER has the capability of deleting local files

T1179

Hooking

RDFSNIFFER hooks several Win32 API functions intended to enable it to tamper with NCR Aloha Command Center Client sessions or hijack elements of its user-interface

Acknowledgements

The authors want to thank Steve Elovitz, Jeremy Koppen, and the many Mandiant incident responders that go toe-to-toe with FIN7 regularly, quietly evicting them from victim environments. We appreciate the thorough detection engineering from Ayako Matsuda and the reverse engineering from FLARE’s Dimiter Andonov, Christopher Gardner and Tyler Dean. A special thanks to FLARE’s Troy Ross for the development of his PE Signature analysis service and for answering our follow-up questions. Shout out to Steve Miller for his hot fire research and Yara anomaly work. And lastly, the rest of the Advanced Practices team for both the unparalleled front-line FIN7 technical intelligence expertise and MITRE ATT&CK automated mapping project – with a particular thanks to Regina Elwell and Barry Vengerik.
